26. May 2021 | Hardware | Noizefield

ALM Busy Circuits released Jumble Henge & AXON-1


ALM Busy Circuits released Jumble Henge, a 16 input stereo spectral mixer with a unique patch-based mixing interface in a compact space and AXON-1, a CV Expander for Squid Salmple.

Jumble Henge
Each input has a carefully tuned resonant analog filter and a unique fixed pan value, providing each sound its own space within the mix. There is a Mix control to adjust the depth of the filtering and a clean external stereo input for chaining with another mixer or extra sound source.

Jumble Henge is a space efficient solution for creating rich stereo mixes from a number of both mono and stereo sources, working great in a compact live system or more creatively explored in the studio. Mix down entire patches, sum stereo effect returns or create a complex feedback network all with an intuitive, musically focused approach.

Jumble Henge was designed in collaboration with Worng Electronics and is based on their existing larger and more featured ‘SoundStage’ module. We appreciated the inspiration from the SP1200’s mixer section and how it nicely relates to the Squid Salmple’s output arrangement.

Features

  • 16 total inputs, 14 with stereo and spectral placement, additional clean stereo input and stereo LR mix output.
  • Intuitive ‘patch-based’ mixing with a unique stereo and spectral position for each input.
  • Per input resonant analog filters carefully tuned to accentuate lows, low mids, high mids, and highs, giving each sound a unique
  • space in the frequency spectrum.
  • Per input fixed pan position with increasing width towards the top end of the frequency spectrum and tighter more centred lows.
  • Equal-power panning for consistency in perceived level across inputs.
  • Mix control allows depth of entire mix’s filtering to be adjusted.
  • Built with audiophile Caps (COG/NPO) and high quality modern OPA audio op amps.
  • Skiff friendly with reverse power protection.
  • Made in England (home of henges)

AXON-1

AXON-1 is a 4HP expander module for the SQUID SALMPLE that provides 4 additional freely assignable CV inputs.

The addition of AXON-1 brings Squid’s total number of CV inputs to 7, greatly increasing the possibilities for vast modular sample manipulation.

Each modulation assignment includes digital attenuation and offset and behaves just like Squid’s 3 built in CV inputs.

AXON-1 requires firmware 166 or later installed on the Squid Salmple to function! Please see the Squid Manual for the update procedure.

Features

  • 4 Additional freely assignable CV inputs for the SQUID SALMPLE
  • Per assignment digital attenuation and offset
  • All assignments and settings saved with banks
  • Powered directly from Squid, no additional power header required
  • Made in England
  • Skiff friendly

More info here: ALM Busy Circuits
