2. December 2021 | Hardware | Noizefield

VoicAs released Q^Mix


VoicAs released Q^Mix, a four channels CV/Audio polarising mixer module for Eurorack.

Q^Mix is a four-channel CV and audio mixer designed to take simple signals and combine them into something altogether new.
The four DC-coupled inputs feature a switch that selects between linear attenuation or bi-polar attenuversion.
Q^Mix can be used to sum simple signals to create much more complex results.
perfect for use as a final volume control when used as an audio mixer.

Technical Specifications

  • All inputs are DC-coupled.
  • Four-channel audio and CV mixer.
  • Logarithmic attenuation on the output stage.
  • Input impedance: 100k for all inputs.
  • Noise filtering and resettable fuses on the module’s power input.
  • Reverse current protection.

Current Draw

  • +12V : 5mA
  • -12V : 5mA

Dimensions

  • Width : 6HP
  • Depth : 10mm

Price
$59

More info here: VoicAs | Q^Mix
